LEVEL 2 FUNCTIONS (ADJUSTABLE PARAMETERS)
Entry
LED
Parameter
LED
(level)
Set value Description
L4
Motor
discharge after
closing
L1 No discharge
Adjusts the duration of the “brief reversal” of both
motors, once the closing manoeuvre terminates,
to reduce the residual nal thrust.
L2 Level 1 - Minimum discharge (roughly 100 ms)
L3 Level 2 - ...
L4 Level 3 - ...
L5 Level 4 - ...
L6 Level 5 - ...
L7 Level 6 - ...
L8 Level 7 - Maximum discharge (roughly 1 s)
L5 Motor force
L1 Level 1 - Minimum force
Adjusts the force of both motors.
L2 Level 2 - ...
L3 Level 3 - ...
L4 Level 4 - ...
L5 Level 5 - ...
L6 Level 6 - ...
L7 Level 7 - ...
L8 Level 8 - Maximum force
L6
Pedestrian or
partial opening
L1
Pedestrian 1 (the M2 gate leaf opens to 1/4 of
the full range)
Adjusts the type of opening associated with the
“partial opening 1” command.
[Note :] “minimum” opening refers to the smallest
opening between M1 and M2; for example, if M1
opens to 90° and M2 opens to 110°, the minimum
opening is 90°.
L2
Pedestrian 2 (the M2 gate leaf opens to 1/2 of
the full range)
L3
Pedestrian 3 (the M2 gate leaf opens to 3/4 of
the full range)
L4 Pedestrian 4 (full opening of gate leaf M2)
L5
Partial 1 (the two gate leaves open to 1/4 of the
“minimum” range)
L6
Partial 2 (the two gate leaves open to 1/2 of the
“minimum” range)
L7
Partial 3 (the two gate leaves open to 3/4 of the
“minimum” range)
L8
Partial 4 (the two gate leaves open to the
“minimum” range)
L7
Maintenance
notice
L1 500
Adjusts the number of manoeuvres after which
the automation maintenance request is triggered
(see the ““Maintenance notice” function”
paragraph).
L2 1000
L3 1500
L4 2500
L5 5000
L6 10000
L7 15000
L8 20000
L8
List of
malfunctions
L1 Result of 1st manoeuvre (most recent)
Allows for checking the type of anomaly that
occurred in the last 8 manoeuvres (see the “
Anomaly log” paragraph).
L2 Result of 2nd manoeuvre
L3 Result of 3rd manoeuvre
L4 Result of 4th manoeuvre
L5 Result of 5th manoeuvre
L6 Result of 6th manoeuvre
L7 Result of 7th manoeuvre
L8 Result of 8th manoeuvre
