ENGLISH – 27
9.6 CONNECTING THE SOLEMYO SOLAR
ENERGY SYSTEM
f
When the automation is powered by the “Solemyo”
system, IT MUST NOT BE POWERED by the elec-
tricity grid at the same time.
l
For information on the “Solemyo” system, consult
the relevant instruction manual.
To connect the “Solemyo” system:
1. remove the cover (A)
2. remove the plastic protection (B) with the aid of a screw-
driver
3. insert the relative connector (C) on the control unit.
C
B
A
53
