7.3 LEVEL 2 PROGRAMMING (ADJUSTABLE PARAMETERS)
All the Level 2 parameters are factory-set as highlighted in “GREY” in “Table 6” and can be modied at any time. The parameters
can be set to a scale of 1 to 8. The check the value corresponding to each LED, refer to “Table 6”.
7.3.1 Level 2 programming procedure
m
The user has maximum 10 seconds to press the buttons consecutively during the programming procedure,
after which time the procedure terminates automatically and memorises the changes made up to then.
To perform Level 2 programming:
1. press and hold the [Stop/Set] button until LED “L1” starts ashing
2. release the [Stop/Set] button when LED “L1” starts ashing
3. press the [Open
p
] or [Close
q
] button to move the ashing LED to the “entry LED” associated with the parameter to be
modied
4. press and hold the [Stop/Set] button. With the [Stop/Set] button pressed:
– wait roughly 3 seconds, until the LED representing the current level of the parameter to be modied lights up
– press the [Open
p
] or [Close
q
] button to shift the LED associated with the parameter’s value
5. release the [Stop/Set] button
6. wait 10 seconds (maximum time) to exit the programming mode.
l
To set multiple parameters during the procedure's execution, repeat the operations from point 2 to point 4 dur-
ing the phase itself.
l
The set value highlighted in grey (“Table 6”) indicates that this value is the factory setting.
Table 6
LEVEL 2 FUNCTIONS (ADJUSTABLE PARAMETERS)
Entry
LED
Parameter
LED
(level)
Set value Description
L1 Pause Time
L1 5 seconds
Adjusts the pause time,
i.e. the time before
automatic re-closure.
Is effective only if
“Automatic Closing” is
enabled.
L2 15 seconds
L3 30 seconds
L4 45 seconds
L5 60 seconds
L6 80 seconds
L7 120 seconds
L8 180 seconds
L2
Step-by-Step
function
L1 Open - Stop - Close - Stop
Controls the sequence of
commands associated
with the “SbS”, “Open”
and “Close” inputs or the
radio control.
[Note :] by setting L4,
L5, L7 and L8, also the
behaviour of the “Open”
and “Close” commands
is modied.
L2 Open - Stop - Close - Open
L3 Open - Close - Open - Close
L4
Condominium: during the opening manoeuvre the “Step-by-Step” and
“Open” commands do not cause any effect, while the “Close” command
causes the movement to reverse, namely closing of the leaves; during
the closing manoeuvre the “Step-by-Step” and “Open” commands
cause the movement to reverse, namely opening of the leaves, while the
“Close” command does not cause any effect.
L5
Condominium 2: during the opening manoeuvre the “Step-by-Step”
and “Open” commands do not cause any effect, while the “Close”
command causes the movement to reverse, namely closing of the gate
leaves. If the sent command remains for more than 2 seconds, a “Stop”
command is executed. During the closing manoeuvre the “Step-by-
Step” and “Open” commands cause the movement to reverse, namely
opening of the leaves, while the “Close” command does not cause any
effect. If the sent command remains for more than 2 seconds, a “Stop”
command is executed.
L6 Step-by-Step 2 (less than 2 sec triggers “Partial Open”)
L7
Hold-to-run: the manoeuvre is only executed if the sent command
remains; if it is interrupted, the manoeuvre stops.
L8 Opening in “semi-automatic” mode, closing in “hold-to-run” mode
L3 Motor speed
L1 Very slow
Adjusts the motor
speed during normal
manoeuvres.
L2 Slow
L3 Medium
L4 Fast
L5 Very fast
L6 Extremely fast
L7 Opens “Fast”; closes “Slow”
L8 Opens “Extremely fast”; closes “Medium”
