SM-Applications Modules & Motion Processors User Guide 11
Issue Number: 4
Safety
Information
Introduction Installation
Getting
Started
Parameters
DPL
Programming
Communications
Freeze and
Marker
CTSync
Inter-option
Synchronization
Diagnostics
Migration
Guide
Quick
Reference
Index
Specifications for SM-Applications Plus
• Enhanced high speed dedicated microprocessor
• 384 kb Flash memory for user program
• 80 kb user program memory
• EIA-RS485 port offering ANSI, Modbus-RTU slave and master and Modbus-
ASCII slave and master protocols
• CTNet high speed network connection offering up to 5 Mbit/s data rate.
• Two 24V digital inputs
• Two 24V digital outputs
• Task based programming system allowing for real-time control of drive and
process
•CTSync
Specifications for SM-Applications Lite V2
• Only supported on SyPTPro V2.4.0 or later
• Only supported on SyPTLite V1.4.0 or later
• Enhanced high speed dedicated microprocessor
• SyPTLite 10 kb executable memory
• 384 kb executable memory, 80 kb user memory.
• Task based programming system allowing for real-time control of drive and
process.
Specifications for Digitax ST Plus Embedded Processor.
• Enhanced high speed dedicated microprocessor
• 384 kb Flash memory for user program
• 80kb user program memory
• EIA-RS485 port offering ANSI, Modbus-RTU slave and master and Modbus-
ASCII slave and master protocols
• CTNet high speed network connection offering up to 5 Mbit/s data rate.
• Two 24V digital inputs
• Two 24V digital outputs
• Task based programming system allowing for real-time control of drive and
process
•CTSync
Specifications for Digitax ST Indexer Embedded Processor.
• Only supported on SyPTPro V2.4.0 or later
• Only supported on SyPTLite V1.4.0 or later
• Enhanced high speed dedicated microprocessor
• SyPTLite 10 kb executable memory
• 384 kb executable memory, 80 kb user memory.
• Task based programming system allowing for real-time control of drive and
process.
