30 SM-Applications Modules & Motion Processors User Guide
Issue Number: 4
Specifies the major revision number of the operating system of the Second Processor.
Use in conjunction with Pr
81.51 to form the complete version number.
Provides the run status of the user DPL program in the Second Processor. The following
values are defined:
Displays the free CPU resource as a percentage of the current background execution
time calculated over 200ms.
Defines the address of this node for ANSI and Modbus communications protocols.
For the ANSI protocol the address range is 11 to 99 where the first digit is the group
address and the second digit is the unit number. Both digits must be in the range of 1-9.
Zero is not permitted since it is used by the master for addressing groups of nodes.
This parameter has no effect if the EIA-RS485 mode is 25 (CTSync) or 26 (CTSync)
Pr 81.02 Firmware Version - Major
Access RO Range 00.00 to 99.99
Default N/A Update Rate N/A
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
Pr 81.03 DPL Program Status
Access RO Range 0 to 3
Default 0 Update Rate 1ms of change
Display Value Description
nonE 0 No DPL program present
StoP 1 DPL program is stopped
run 2 DPL program is running
triP 3
Run-time error. ERROR task running or
DPL program stopped
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
Pr 81.04 Available System Resource
Access RO Range 0 to 100
Default N/A Update Rate 200ms
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
Pr 81.05 EIA-RS485 Address
Access RW Range 0 to 255
Default 11 Update Rate Initialization
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer
