SM-Applications Modules & Motion Processors User Guide 53
Issue Number: 4
Safety
Information
Introduction Installation
Getting
Started
Parameters
DPL
Programming
Communications
Freeze and
Marker
CTSync
Inter-option
Synchronization
Diagnostics
Migration
Guide
Quick
Reference
Index
For description see below
For description see below.
For description see below.
For description see below.
The four parameters above (Pr
90.12 - Pr 90.15) give the reason why the particular
EVENT task was scheduled. The value only has meaning when the particular EVENT
task is running.
The value is bitmapped and defined as follows:
Pr 90.12 Event task schedule reason
Access RO Range Unsigned 16-bit
Default N/A Update Rate On Event
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer

Pr 90.13 Event1 task schedule reason
Access RO Range Unsigned 16-bit
Default N/A Update Rate On Event1
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer

Pr 90.14 Event2 task schedule reason
Access RO Range Unsigned 16-bit
Default N/A Update Rate On Event2
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer

Pr 90.15 Event3 task schedule reason
Access RO Range Unsigned 16-bit
Default N/A Update Rate On Event3
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer

Bits Description Value
0-1 Slot triggering the task
0 = Local slot
1 = Slot 1
2 = Slot 2
3 = Slot 3 or Embedded
2-7 Reason for trigger.
0-31 = Other option module initiated
32 = CTNet Sync
33 = Timer Unit
34-63 = User-defined reason via the DPL command
SCHEDULEEVENT.
