22
Step 8: Connect the Power Cable
Connecting the Scanner to a Power Source
Before connecting the power cables, be sure the scanner is off. Attach the female end of the power
cable to the AC connector on the rear of the scanner and insert the male end into a general-purpose
(AC 100–240 V, 50/60 Hz) household outlet.
Shape of plug varies with country of purchase. Be
sure that the socket to which the scanner is con-
nected is grounded; if a separate ground wire is pro-
vided, be sure to attach the ground wire to the earth
connector.
Power switch off
Power switch on
To Next Page
