- R3
･
-
VBA18001-R.3719.A
Jan.25.2008
Additional page
Items Judgment standard Remarks
Viewfinder
Inner LCD lower
panel window position
Inner LCD right panel
window position
(frame coverage)
Parallax
(Difference of center
from the shot image/
sensor)
Eye point
Up-down position:
(a = window width)
Tilt: １° or less
(a = window width)
Tilt: 1° or less
Lens vignetting/distortion: No outstanding vignetting/distortion
Tilt: (based on Bottom cover): 20’ or less
Relative angle to image sensor: 30’ or less
In height and width: 100
＋ 0％
－ 2％
Up-down: 0.2 mm or less
Right-left: 0.2 mm or less
Distance to eyepiece protective glass:
(In case of "- 1 m
－１
"): 16.2 - 19.8mm (18 mm ± 10%)
Visual check
AF50/1.4D, F5.6
Looking through view-
finder, measure a tilt of
indication line (parallel
to the bottom) from
the bottom line of the
frame.
AF50/1.4D, F5.6
Mark a line indicating
the field of viewfinder
and take a picture.
Then, measure a
difference (tilt) between
the marked indication
line and actual shot.
Vernier caliper
Eye point tool
Screen misalignment Tilt: 30’ or less E screen
B screen
Special chart
Sequence
Release time lag AF-M: 47 ms or less
AF-C: 47 ms or less
Release with a one push: 210 ms or less
Release when vibration reduction lens attached: : 100 ms or less
100 ms or less
Oscilloscope
Constant-voltage
power source
Power tool
EV9
AF-S VR70-200ED,
F2.8G
AF-M, AE-A, AMP
SB-800 (Multi-
sensor balanced fill-
flash)
Focused state
Measure the time
taken from releasing
the shutter to
switching ON for
X-signal.
To Next Page
