- R6
･
-
VBA18001-R.3719.A
Jan.25.2008
Additional page
Items Judgment standard Remarks
Image-
related
Appropriate
level
Judgment method
When RAW recorded:
ｘ 425 pixels which was away from the
center of screen to the right by 425 pixels, calculate the average of G-14
bit data.
When JPEG recorded:
ｘ 425 pixels which was away from the
center of screen to the right by 425 pixels, calculate the average of Y-8 bit
data.
Standard
Lo 1 3428±200 (±0.1EV)
Lo 0.7 2717±160 (±0.1EV)
Lo 0.5 2421±145 (±0.1EV)
Lo 0.3 2158±130 (±0.1EV)
ISO 200~ISO6400 1714±100 (±0.1EV)
[TIFF, JPEG]
・Standard Lo 1, Lo 0.7, Lo 0.5, Lo 0.3, ISO200~6400 134~144
・Neutral Lo 1, Lo 0.7, Lo 0.5, Lo 0.3, ISO200~6400 131~140
・Vivid Lo 1, Lo 0.7, Lo 0.5, Lo 0.3, ISO200~6400 132~144
AF50mm/F1.4D (CPU built-in
metering reference lens)
F5.6
Lo 1 1/15 LV10+ND2
Lo 0.7 1/20 LV10+ND2
Lo 0.3 1/25 LV10+ND2
ISO200 1/30 LV10+ND2
ISO250 1/20 LV10+ND4
ISO320 1/25 LV10+ND4
ISO400 1/30 LV10+ND4
ISO500 1/20 LV10+ND8
ISO640 1/25 LV10+ND8
ISO800 1/30 LV10+ND8
ISO1000 1/20 LV10+ND16
ISO1250 1/25 LV10+ND16
ISO1600 1/30 LV10+ND16
ISO2000 1/20 LV10+ND32
ISO2500 1/25 LV10+ND32
ISO3200 1/30 LV10+ND32
ISO4000 1/20 LV10+ND64
ISO5000 1/25 LV10+ND64
ISO6400 1/30 LV10+ND64
AE: M mode
Distance from object: Closely
contact
Image size: L, M, S
(for every sensitivity)
Resolution Judgment method
Take a shot of the chart by matching the central 1/2 screen with the
vertical angle of view.
Adjust the speed so that brightness becomes 220 ± 5 LSB (8bit) at white
part about the center of chart.
Standard
Horizontal resolution
1900 TV lines or more
Vertical resolution
Horizontal resolution
1800 TV lines or more
Vertical resolution
AFS80-200 mm/F2.8D
105 mm
F5.6
AE: M mode
Image size: L
ISO200
Pixel defects:
against dark
background
Judgment method
Judge the level of white pixels
Standard
At 25℃ : 30 LSB or less
At 40℃ : 60 LSB or less
Lens cap
Shutter speed: 1/30
AE: M mode
Image size: L
Temperature:
25±2℃ , 40
+5
-0
℃
ISO200
To Next Page
