Nikon D3 VBA18001 - Page 37

- Ｄ  ･ -
VBA18001-R.3719.A
logo�Q0440�forGraphic
070518�Gdesign�ito
・
Remove the F-F0 plate (#5046).
・
Take out the screw (#1510).
・
Remove the lens contacts unit (#B10411).
Lens contact unit
・
Take out the screw (#47).
・
Remove the remote connector (#41).
Remote connector
#41
#47
#1510
#B10411
#408
#412
#5046
#409
INC
