- Ａ ･ -
VBA18001-R.3719.A
logo�Q0440�forGraphic
070518�Gdesign�ito
①
Inspection & adjustment of AE CCD positioning (ref. Page A31
）
②
AE accuracy inspection & adjustment
Inspect and adjust by using the following types of lens (AF50/1.4D, AF28/2.8D, AF70-300/4-5.6D or AF-
SVR70-300/4.5-5.6).
Caution:
AE accuracy is not inspected by using the exposure value of the shutter tester, which was the conventional
method. The metering value is displayed on PC screen.
③
Aperture accuracy inspection & adjustment
Remove the lens when adjusted.
Caution: The aperture pulse number is displayed on PC screen for inspecting aperture.
④
M1/8000 accuracy inspection & adjustment
⑤
Monitor adjustment
Inspection and adjust via USB with the DG-PCB and top cover(temporarily assembled) being mounted.
⑥
AE sensor inspection & adjustment
Caution: Set the metering mode to " Matrix metering" .
Install of USB driver
For using the adjustment software, connect the camera via USB and install USB driver. For "Windows2000",
install the driver that is supplied with the software, while "WindowsXP", installing the driver is not necessary
because the OS already incorporates the driver.
Before connecting the camera and PC, set USB to "PTP".
（
Setup menu → USB → PTP
）
Camera body AE adjustment (other than imaging-related)
AE inspection and adjustment
To Next Page
