668
Radio AWL
5
f
: Establish a wireless connection between the
WR-R10 and the remote flash units.
•
Set the remote units to radio AWL remote mode.
•
Set the remote units to the channel you selected for the
WR-R10 in Step 3.
•
Pair each of the remote units with the WR-R10 according to
the option selected in Step 4:
-[Pairing]: Initiate pairing on the remote unit and press the
WR-R10 pairing button. Pairing is complete when the
LINK lamps on the WR-R10 and flash unit flash orange and
green. Once a connection is established, the LINK lamp on
the remote flash unit will light green.
-[PIN]: Use the controls on the remote flash unit to enter
the PIN you selected in the previous step. Pairing begins
when the PIN is entered. Once a connection is
established, the LINK lamp on the remote flash unit will
light green.
6
f
: Repeat Step 5 for the remaining remote units.
