Operating Posture
IX
IC Inspection Microscope ECLIPSE L200ND / L200N Instructions
Operating Posture
The figure below shows the posture that prevents strain on your body when you operate this
equipment.
Choose a workbench and a chair having the similar dimensions to those shown on the
figure.
510
The 5th percentile female (Height: 1475 mm)
(The front
clearance for
the knees)
405 (The height of the seating surface)
1253 (The height of the eye point)
510
1138 (The height of the eye point)
690
470 (The height of the seating surface)
760
The 95th percentile male (Height: 1895 mm)
760
690
(The height of the workbench)
(The upper clearance
for the knees)
70
(The height of the workbench)
(The front clearance
for the knees)
(The upper clearance
for the knees)
Dimensions are in mm.
Figure-3 Operating posture
