1 Names of the Parts
3
IC Inspection Microscope ECLIPSE L200ND / L200N Instructions
Focusing target lever
Filter sliders
Aperture diaphragm
centering screw holes
Screw hole for carrying rod
Screw holes for AF drive
Slots for diascopic illumination
filter (for L200ND only)
Coarse focus stopper ring
Filter sliders
Figure-6 Names of the operational parts (2)
“Caution for heat” symbol
CAUTION label
Connector for
episcopic lamphouse
Connector for
diascopic lamphouse
Power cord
AC IN connector
Power switch
Input voltage indication
Screw holes for carrying
rods
USB connector
(For connecting a PC or
the DS-L2 digital camera)
HGFIE connector
(For connecting the
C-HGFIE HG Precentered
Fiber Illuminator (motorized
type))
Figure-7 Names of the operational parts (3)
