7210 SAS-D CHASSIS INSTALLATION GUIDE Transceivers
Issue: 08 3HE 10087 AAAA TQZZA Edition 01 51
Step 4. Place the SFP on an anti-static mat or in an electrostatic bag.
Step 5. Install a replacement SFP into the port.
Step 6. Connect the fiber or copper cable, or if you are not immediately connecting
a fiber cable, insert a protective plug into the SFP optical port and place a
dust cover on the fiber cable connector.
Caution: The 7210 SAS-D does not use a fan for cooling and the SFPs might be hot to the
touch. Avoid direct contact with the metal casing of the SFPs.
