7.1 Specifications
7.1.1 7210 SAS-D Chassis
The following specifications apply to the 7210 SAS-D (non-ETR) chassis.
Table 14 7210 SAS-D Specifications
Item Description
Physical dimensions
Size Height: 1.69 in. (1.5RU) (4.28 cm)
Weight: 10.43 in. (26.5 cm)
Depth: 6.89 in. (17.5 cm)
Weight 3 lbs (1.36 kg)
Environmental
Operating Temperature 32ºF to 104ºF (0ºC to 40ºC) (standard) IEC 68-2-14
Humidity 5 to 95% non-condensing
Altitude 1800 m, 50°C
4000 m, 40°C
Vibration IEC 68-2-36, IEC 68-2-6
Shock IEC 68-2-29
Drop IEC 68-2-32
Telcordia NEBS Design to meet NEBS level 3
Input
Input voltage –36VDC to –72VDC, Output: +12VDC
100 to 240 V, 50 to 60 Hz, Output: +12VDC
Maximum power
consumption
30 W
