7210 SAS-D CHASSIS INSTALLATION GUIDE Specifications
Issue: 08 3HE 10087 AAAA TQZZA Edition 01 75
7.1.2 7210 SAS-D ETR Chassis
The following specifications apply to the 7210 SAS-D ETR chassis.
Table 15 7210 SAS-D ETR Specifications
Item Width
Physical dimensions
Size Height: 1.75 in. (1.5RU) (4.4 cm)
Width: 10.5 in. (26.7 cm)
Depth: 7.0 in. (17.8 cm)
Weight 3 lbs (1.36 kg)
Environmental
Operating Temperature –40ºF to 149ºF (–40ºC to 65ºC) (standard) IEC 68-2-14
Humidity 5% to 95% non-condensing
Altitude 1800 m, 50°C
4000 m, 40°C
Vibration IEC 68-2-36, IEC 68-2-6
Shock IEC 68-2-29
Drop IEC 68-2-32
Telcordia NEBS Design to meet NEBS level 3
Input
Input voltage –36VDC to –72VDC, Output: +12VDC
100 to 240 V, 50 to 60 Hz, Output: +12VDC
+20VDC to +28VDC, Output: +24VDC
Dual input power redundancy, with current sharing and
hot-swap.
Maximum power
consumption
30 W
