Configuring the System
58
7210 SAS-D CHASSIS INSTALLATION GUIDE
3HE 10087 AAAA TQZZA Edition 01 Issue: 08
After the 7210 SAS-D boots up, you should see the following prompt:
All rights reserved. All use subject to applicable license agreements.
Built on Wed Apr 20 14:32:04 IST 2011 by builder in /builder/3.0B5/panos/main
Login:
Both the default username and password are admin. Log into the 7210 SAS-D.
To establish either a console connection or Telnet connection to the switch after a
successful boot, please see section 5.3
5.2.1.2 Booting from the Network
You can use one of the front panel ports (referred to as uplinkA and uplinkB in the
display output shown below) to boot the 7210 SAS-D from the network. The example
below shows how to boot the device with the out-of-band management port and
without it using the manual boot process. For more information on how the boot
process works in 7210 SAS-D, please refer to the System Basics guide. Figure 22
shows the network diagram used in the example below.
Additionally, you may want to store the TiMOS image on the internal flash if you want
to boot from the flash later.
Figure 22 7210 SAS-D Boot Process
You will need the following:
• An FTP server
Note: The SYS LED will be green when the device has successfully completed the boot
process and is running normally.
OSSG552
FTP
Server
IP Address:
10.10.170.22/24
Port: 7
IP Address: 10.135.4.172/24
Gateway: 10.135.4.1
Console Cable
SAS-D
