Console Connection
82
7210 SAS-D CHASSIS INSTALLATION GUIDE
3HE 10087 AAAA TQZZA Edition 01 Issue: 08
Figure 23 Console Port Alarm Connection
External Alarm Relays
On Other Equipment
Refer to HW Install Guide
for Minimum Cable Specification
and Maximum Allowed Cable Length.
Console
RJ-45
Alarm
TXD
RXD
Warning: Do Not Apply Any
External Voltage to Pin 3 or Pin 6
Alarm
Off Active
N/C Pin 1
N/C Pin 2
GND Pin 4
GND Pin 5
Pin 3
Pin 6
N/C Pin 7
N/C Pin 8
al_0606
