Nokia E66 User Manual

2. Insert the memory card in the slot with the contact
area first. Make sure that the contact area is facing
the connectors on the device.
3. Push the card in until it locks into place.
4. Close the back cover.
Eject the memory card
Important: Do not remove the memory card in
the middle of an operation when the card is being
accessed. Removing the card in the middle of an
operation may damage the memory card as well as the
device, and data stored on the card may be corrupted.
1. Press the power key briefly, and select Remove
memory card.
2. Press the release buttons and slide off the back
cover.
3. Press the end of the memory card to release it from
the memory card slot.
4. Close the back cover.
Connect the headset
Warning: When you use the headset, your ability
to hear outside sounds may be affected. Do not use the
headset where it can endanger your safety.
Connect the compatible headset to the headset
connector of your device.
Attach the wrist strap
Thread the wrist strap as shown, and tighten it.
19
Set up your device

Nokia E66 Specifications

General

Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Phonebook capacity	100 entries
Internal memory	110 MB
Sensor type	CMOS
Digital zoom	4 x
Rear camera type	Single camera
Rear camera resolution	2048 x 1536 pixels
Video capture resolution (max)	640 x 480 pixels
Headphone connectivity	2.5 mm
USB 2.0 ports quantity	1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Personal info management (PIM)	Alarm clock, Calculator, Calendar, To-do list
Form factor	Slider
Product color	Gray
Talk time (2G)	7 h
Battery capacity	1000 mAh
Standby time (2G)	264 h
2G standards	EDGE, GPRS
Data network	3G, wcdma
Bluetooth version	2.0+EDR

Weight and Dimensions

Depth	13.6 mm
Width	49.5 mm
Height	107.5 mm
Weight	121 g
