1 Overview
22 Nokia EM5400 IP Security Platform (IP260 and IP265 Appliances) Installation Guide
Figure 2 Component Locations Rear View
Built-in Ethernet Ports
Figure 3 shows the layout of the built-in Ethernet ports and LEDs.
Figure 3 Built-In Ethernet Interface Front Panel Details
Note
Nokia products support NICs purchased from Nokia Corporation or
Nokia-approved resellers only. The Nokia Global Support Services group
can provide support only for Nokia products that use Nokia-approved
accessories. For sales or reseller information, contact a Nokia service
provider listed in the “Nokia Contact Information” on page 3.
00321
Power plug
Power switch
00120
Activity LED (yellow)
Link LED (green)
RJ-45 connectors
