Nokia EM5400 - Figure 11 Ethernet Crossover Cable Pin Connections

4 Connecting to the Ethernet Ports
50 Nokia EM5400 IP Security Platform (IP260 and IP265 Appliances) Installation Guide
The following figure shows the pin assignments for the RJ-45 crossover
cable.
Figure 11 Ethernet Crossover Cable Pin Connections
00017.1
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
EM5400 IP Security Platform includes IP260, IP265, 50i, 50s Appliances
