Nokia EM5400 IP Security Platform Appliance Overview
Nokia EM5400 IP Security Platform (IP260 and IP265 Appliances) Installation Guide 23
Console and Serial (AUX) Ports
Use the built-in console port to supply the information that makes the
appliance available on the network. Use the built-in serial (AUX) port for
RS232-compliant equipment you are using with your appliance; for example,
as a modem connection for managing the appliance. Figure 4 provides pin
assignment information for console and serial connections.
Caution
Nokia recommends that you use the console cable that was
delivered with your appliance for your console connection.
Otherwise, ensure that the pin assignments for your cable match
those provided in this section.
Note
Although pin assignments are the same for console and serial
connections, they are used differently by the appliance. Therefore, do not
use these two connectors interchangeably.
EM5400 IP Security Platform includes IP260, IP265, 50i, 50s Appliances
