General information
RM-634 product data
RM-634 (Nokia E5–00.2) is an LTA variant of the RM-632.
The key product data differences between the RM-632 and RM-634 are described below.
Connectivity
Table 11 Remote connectivity
Operating bands RM-634: EGSM 850/900/1800/1900, WCDMA/HSDPA
850/1900/2100 (V/II/I)
Main RF characteristics for GSM850/900/1800/1900 and WCDMA V (850), WCDMA II (1900) and
WCDMA I (2100) phones
Parameter Unit
Cellular system GSM850, EGSM900, GSM1800/1900, WCDMA V (850), WCDMA II
(1900) and WCDMA I (2100)
Rx frequency band GSM850: 869 - 894MHz
EGSM900: 925 - 960 MHz
GSM1800: 1805 - 1880 MHz
GSM1900: 1930 - 1990 MHz
WCDMA V (850): 871 - 892 MHz
WCDMA II (1900): 1932 - 1988 MHz
WCDMA I (2100): 2110 - 2170 MHz
Tx frequency band GSM850: 824 - 849MHz
EGSM900: 880 - 915 MHz
GSM1800: 1710 - 1785 MHz
GSM1900: 1850 - 1910 MHz
WCDMA V (850): 826 - 847 MHz
WCDMA II (1900): 1852 - 1908 MHz
WCDMA I (2100): 1920 - 1980 MHz
Output power GSM850: +5 ...+32.5dBm/3.2mW ... 2W
GSM900: +5 … +32.5dBm/3.2mW … 2W
GSM1800: +0 … +30dBm/1.0mW … 1W
GSM1900: +0 … +30dBm/1.0mW … 1W
WCDMA V (850): -50 ... +23 dBm/0.01μW ... 199.5mW
WCDMA II (1900): -50 ... +22 dBm/0.01μW ... 158.5mW
WCDMA I (2100): -50 ... +23 dBm/0.01μW ... 199.5mW
RM-632; RM-634; RM-699
Service information differences between RM-632 and
RM-634
