Nokia RM-632 - WLAN Functionality Testing Concept with

Type Description
SB-6 Bluetooth test and interface box
Smart card reader
PC with Phoenix service software
Cables
DAU-9S MBUS cable
PCS-1 DC power cable
USB cable
WLAN functionality testing concept with SB-7
Figure 8 WLAN functionality testing concept with SB-7
Type Description
Product specific tools
FS-147 Flash adapter
Other tools
CU-4 Control unit
PCS-1 DC power cable
PK-1 SW Security device
Note: PK-1 can be used instead of PKD-1.
SS-62 Generic base adapter
Cables
RM-632; RM-634; RM-699
