Type Description
PCS-1 Power cable
CA-89DS Service cable
Standard USB cable
USB cable
Module jig service concept
Figure 5 Module jig service concept
Type Description
Phone specific devices
MJ-266 Module jig
Other devices
CU-4 Control unit
FPS-21 Flash prommer box
PK-1/PKD-1 SW security device
SX-4 Smart card
PC with VPOS and Phoenix service software
Measurement equipment
RM-632; RM-634; RM-699
Service Devices and Service Concepts
Issue 3 COMPANY CONFIDENTIAL Page 2 – 15
Copyright © 2010 Nokia. All rights reserved.
