Parts
7-3
Part 1024496_06
2014 Nordson Corporation
Item Used Part Description Quantity Note
1 ‐ ‐ ‐ ‐ ‐ ‐
Pump, piston
1 A, B
2 P4, P7 ‐ ‐ ‐ ‐ ‐ ‐
Manifold assembly, 4-hose, 230 V
1 C
P10 ‐ ‐ ‐ ‐ ‐ ‐
Manifold assembly, 6-hose, 480 V
1 C
P4, P7 ‐ ‐ ‐ ‐ ‐ ‐
Manifold assembly, 6-hose, 230 V
1 C
P10 ‐ ‐ ‐ ‐ ‐ ‐
Manifold assembly, 6-hose, 480 V
1 C
3 P4 1051033
Kit, service, tank, P4, 230V
1 F
P7 1051034
Kit, service, tank, P7, 230V
1 F
P10 1051035
Kit, service, tank, P10, 230V
1 F
4 ‐ ‐ ‐ ‐ ‐ ‐
Heater block, ProBlue
1 F, G
5 1017009
Screw, manifold mounting, M8
3
6 1017060
Screw, pump mounting, M8
3
7 ‐ ‐ ‐ ‐ ‐ ‐
Thermostat, OOR, 500 degree, push-on
1 D
8 1018189
Clip, retaining, RTD
1
9 1017186
Tube, cross-over, tank
1
10 941161 O-ring, Viton, 0.750 x 0.938 x 0.094 in. 2
11 1017189
Tube, cross-over, pump
1
12 940133 O-ring, Viton, 0.426 x 0.070 in. 2
13 P4 1022747
Screen, inlet, pump, P4
1
P7 1025885
Screen, inlet, pump, P7
1
P10 1017892
Screen, inlet, pump, P10
1
14 1028320
Sensor, temperature, RTD
2 E
15 954013
Backup ring, PTFE
2
NS P4 1029997
Insulation, tank, P4
1
P7 1030557
Insulation, tank, P7
1
P10 1030556
Insulation, tank, P10
1
NOTE A: Refer to Pump Assembly Parts Lists.
B: Included in service kit. Refer to Service Kits for part numbers.
C: Included in service kit P/N 1064651, 1064652, 1064653, or 1064654. Refer to Service Kits.
D: Included in service kit P/N 1028321.
E: Kit P/N 1028320 contains 1 RTD.
F: Refer to Appendix E for 400/480 Volt melter parts.
