Up to three numbers for sending SMS can be stored
into LDSCD memory. SMS recipient will receive an
SMS containing instrument ID, NAME and status.
Number formats can be stored using international
prefix “+”, international prefix “00” or local.
WARNING: THIS FUNCTION COULD NOT BE
FREE OF CHARGE. DEPENDING ON YOUR OPERATOR CONTRACT IT
COULD GENERATE PAYING SMS TRAFFIC !
To enable warning message for related alarm
condition choose “YES”, to disable choose “NO”.
Then move wheel on Exit and SAVE configuration.
SMS will be sent when one or more (“YES”) elds
will change.
E.g.:
LCD1 or 2 : level alarm for PH1 or PH2 levels
LCD: level alarm for Conductivity
FLOW: flow alarm
ALCL: out of reading range for Conductivity probe
WARNING: TO AVOID UNDESIRED MESSAGES USE CAREFULLY THIS
SETUP!
Appendix Communication HARDWARE - “SMS/GSM” Module
Located under mainboard cover there is a four pins connector that can be used to install USB, ETHERNET or MODEM
modules. Modules come pre-installed upon request and may appear different as shown (different configurations).
“SMS/GMS module” can be congured to send SMS messages containing critical instrument information.
To obtain reliable results with this feature please check the following list:
- Make certain the antenna location is not shielded by metal objects or near sources of electrical ‘noise’.
- Do not route the cable where it could be pinched in doors, windows etc.
- Secure the antenna cable
- Ensure that SIM into “SMS/GSM modeule” is properly inserted, activated and within operator range.
- Set instrument ID / NAME from “RS485 Setup” menu and configure “Out of Range Alarm” menu.
Within “Main menu” select “SMS MENU” to enable SMS service and enter SMS receiver phone numbers.
Insert here standard
SIM
Unplug instrument
from main supply
before to open it.
GSM modem antenna connector
