Nortec GS - Overall Dimensions and Weight

21Installation
Nortec GS
2583703_EN_1608
Table 9: Required Clearances*
Model
Overhead
Clearance "A"
Right Side
Clearance "B"
Ground
Clearance "C"
Front
Clearance "D"
Left Side
Clearance "E"
Rear Clearance
"F"
GS 50 16 in (406 mm) 24 in (610 mm) 24 in (610 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 100 16 in (406 mm) 24 in (610 mm) 24 in (610 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 150 16 in (406 mm) 24 in (610 mm) 0 in (0 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 200 16 in (406 mm) 24 in (610 mm) 0 in (0 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 300 16 in (406 mm) 24 in (610 mm) 0 in (0 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 450 16 in (406 mm) 24 in (610 mm) 0 in (0 mm) 36 in (914 mm)
24 in (610 mm)
0 in (0 mm)
GS 600 16 in (406 mm) 24 in (610 mm) 0 in (0 mm) 36 in (914 mm)
24 in (610 mm)
0 in (0 mm)
* Consult local and national installation codes.
Table 10: Suggested Clearances
Model
Overhead
Clearance "A"
Right Side
Clearance "B"
Ground
Clearance "C"
Front
Clearance "D"
Left Side
Clearance "E"
Rear Clearance
"F"
GS 50 36 in (914 mm) 30 in (762 mm) 24 in (610 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 100 36 in (914 mm) 30 in (762 mm) 24 in (610 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 150 36 in (914 mm) 30 in (762 mm) 0 in (0 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 200 36 in (914 mm) 30 in (762 mm) 0 in (0 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 300 36 in (914 mm) 30 in (762 mm) 0 in (0 mm) 36 in (914 mm) 0 in (0 mm) 0 in (0 mm)
GS 450 36 in (914 mm) 30 in (762 mm) 0 in (0 mm) 36 in (914 mm)
30 in (762 mm)
0 in (0 mm)
GS 600 36 in (914 mm) 30 in (762 mm) 0 in (0 mm) 36 in (914 mm)
30 in (762 mm)
0 in (0 mm)
5.4.1.1 Overall Dimensions and Weight
The overall dimensions and weight of the Nortec GS humidier are listed in Table 11. Note: The dimen-
sions and weights shown do not include the oor stand or wall mount bracket.
Table 11: Nortec GS Humidier Overall Dimensions and Weights
Model
Dimensions Weight
Height Width Depth Net Operating
GS 50-CS/NX 43.4 in (1102 mm) 23.5 in (598 mm) 21.2 in (539 mm) 190 lb (86.2 kg) 340 lb (154.2 kg)
GS 100-CS/NX 43.4 in (1102 mm) 23.5 in (598 mm) 21.2 in (539 mm) 210 lb (95.3 kg) 365 lb (165.6 kg)
GS 150-CS/NX 55.5 in (1410 mm) 27.0 in (684 mm) 27.7 in (705 mm) 320 lb (145.1 kg) 500 lb (226.8 kg)
GS 200-CS/NX 55.5 in (1410 mm) 37.8 in (960 mm) 27.7 in (705 mm) 480 lb (217.7 kg) 775 lb (351.5 kg)
GS 300-CS/NX 55.5 in (1410 mm) 37.8 in (960 mm) 27.7 in (705 mm) 480 lb (217.7 kg) 800 lb (362.8 kg)
GS 450-CS/NX 55.5 in (1410 mm) 62.2 in (1580 mm) 27.7 in (705 mm) 800 lb (362.9 kg) 1200 lb (544.3 kg)
GS 600-CS/NX 55.5 in (1410 mm) 73.2 in (1859 mm) 27.7 in (705 mm) 910 lb (412.8 kg) 1550 lb (703.1 kg)
