Nortec GS - Standard Floor Stand Mounting - Compact Unit Only

24 Installation
2583703_EN_1608 Nortec GS
5.4.3 Standard Floor Stand Mounting – Compact Unit Only
Install the compact Nortec GS humidier on the oor stand, if desired, as follows. Refer to Figure 9 on
page 25.
1. Check that the selected mounting location provides adequate clearances for maintenance. Refer to
"Clearances" on page 20.
2. Remove all the packaging material around the Nortec GS humidier that was used for shipping the
unit. Remove the accessory box and open its contents.
3. Assemble the oor stand using the instructions in the accessory box.
4. Make sure that the oor is hard and level, then set the oor stand on the oor (and optionally against a
wall or other suitable vertical mounting surface). Level the stand using the leveling screws on its feet.
Note: If desired, remove the leveling screws and secure the oor stand to the oor with 3/8 in bolts
and washers (not supplied).
5. Remove the door panels from the humidier.
6. Remove and discard the two shipping screws that secure the unit to the shipping pallet.
WARNING!
Heavy object – risk of personal injury, or damage to equipment!
Prevention: Use an appropriate lifting device to lift the humidier. Lift the unit from the bottom,
and not the side or top panels.
7. Carefully lift the humidier by its base frame and raise it off the shipping pallet.
8. Carefully lower the humidier onto the oor stand.
9. Install four M6×12 bolts and washers (supplied) and secure the humidier to the oor stand. Torque
the bolts to 9 N·m.
10. Install the two L-brackets on the top of the unit (optional) with the sheetmetal screws (supplied).
11. Secure the L-brackets to the vertical mounting surface with two 1/4 in lag bolts and washers (not
supplied).
12. Install the door panels.
