5.4.5 Optional Stand Mounting – Full-Size Unit
Install the full-size Nortec GS humidier on an optional mounting stand as follows. Refer to Figure 11.
1. Check that the selected mounting location provides adequate clearances for maintenance. Refer
to "Clearances" on page 20.
2. Remove all the packaging material around the Nortec GS humidier that was used for shipping the
unit. Remove the accessory box and open its contents.
3. Assemble the mounting stand using the instructions in the accessory box.
4. Set the mounting stand on a hard level oor, and level it using shims, if necessary.
Note: If desired, secure the mounting stand to the oor with 3/8 in bolts and washers (not supplied).
WARNING!
Heavy object – risk of personal injury, or damage to equipment!
Prevention: Use an appropriate lifting device to lift the humidier. Lift the unit from the bottom,
and not the side or top panels
5. Carefully lift the humidier by its base frame and raise it off the shipping pallet. Lower it onto the
mounting stand. Check that it is seated properly.
Figure 11:
1
2
Optional Mounting, Full-Size Unit (GS 150 Shown)
1 Bolt, 3/8×2 in (×4, not supplied)
2 Washer, at, 3/8 in (×4, not supplied)
