Nortec GS - Standard Mounting - Full-Size Unit

26 Installation
2583703_EN_1608 Nortec GS
5.4.4 Standard Mounting – Full-Size Unit
Install the full-size Nortec GS humidier directly on the oor as follows. Refer to Figure 10.
1. Check that the selected mounting location provides adequate clearances for maintenance. Refer to
"Clearances" on page 20.
2. Remove all the packaging material around the Nortec GS humidier that was used for shipping the unit.
WARNING!
Heavy object – risk of personal injury, or damage to equipment!
Prevention: Use an appropriate lifting device to lift the humidier. Lift the unit from the bottom,
and not the side or top panels
3. Carefully lift the humidier by its base frame and raise it off the shipping pallet. Lower it onto a hard
level oor.
4. Add shims under the frame brackets, if necessary, to level the unit.
Note: If desired, secure the unit to the oor with 3/8 in bolts and washers (not supplied).
Figure 10:
1
2
3
Standard Mounting, Full-Size Unit (GS 150 Shown)
1 Bolt, 3/8×2 in (×4, not supplied)
2 Washer, at, 3/8 in (×4, not supplied)
3 Bracket, frame
