6.8 Input of battery data
The charging program by the UL 10 device depends on the entered data of batteries and the se-
lected operation type. The data is required about the type and the battery parameters for the entered
data to enable proper execution of the program.
6.8.1 General
When inputting the battery type and parameters the operation type is selected and the program is
assigned automatically that the UL10 device should use. For proper execution of programs the data
is needed about the composition of the connected battery.
6.8.2 Operation without battery Р:00
When there is no battery (the battery is at 00) only one operation type 8 is possible, or the device is
enabled just as a source of direct current voltage.
There is an option «the battery is not connected + discharge» = program 000. In this case the final
discharge voltage and final current are indicated.
This program is disabled; it is enabled by an additional request from the customer because there is
a risk of ruining the battery.
6.8.3 Operation without Lead acid batteries
The information below relates to aluminum types of batteries with the data input starting with 1х.
Below is the full list of the types in question:
• Type 10: air-tight aircraft lead acid electrolyte-filled batteries
• Type 11: standard air-tight lead acid electrolyte-filled batteries
• Type 16: standard enclosed lead acid electrolyte-filled batteries
After the type is selected with the keys 4 and 6 it is confirmed by hitting Enter↵ and the operation
type is to be entered.
For lead acid batteries all methods of maintenance can be used. For example, when "maintenance
of air-tight aircraft lead acid batteries” is selected hit 6 and proceed to the required operation type,
confirm by hitting Enter. The LED message is:
The input of parameters
Nominal voltage
The battery nominal voltage should be entered. It is shown on the next tag. It is 12 V usually. The
UL 10 device can be used for connecting several batteries in series in exceptional cases.
Batteries with different nominal capacities should be not connected to the mains in series.
P 410: PARAMETER INPUT
NOMINAL VOLTAGE 00 0V
To Next Page
