Nortec UL10 - Program 216. Charging - Pb Battery Vented Commercial

CHARGER / DISCAHRGER UL10 OPERATION MAUNAL
© NorTec Electronics 2014
49
7.13 Program 216. Charging – Pb battery vented commercial
Stage name Maximum
duration
Program number 216
Operation number 2
Operation type Charging
Battery type Lead acid
Manufacturing process Liquid electrolyte
Access to valves open
Battery type 16
Minimum battery capacity 10 Ah
Maximum battery capacity 400 Ah
Minimum battery voltage 2
Maximum battery voltage 30
Maximum number of batteries 15
For voltages > 2.25 V/battery
Stage 1 (S1) Precharge Umax = V/battery 2,4 6 h
Stage 1 (S1) Precharge Iа = xС (A) 0,25 6 h
Stage 2 (S2) I-Charge Current = xС (A) 0,25 8 h
Stage 2 (S2) I-Charge Umax = V/battery 2,4 8 h
Stage 3 (S3) U-Charge Umax = V/battery 2,4 8 h
Stage 3 (S3) U-Charge I а= xС (A) 0,04 8 h
Stage 4 (S4) U-Charge U = V/battery 2,4 2 h
Note: when the maximum output current of the device is exceeded the maximum time para-
meters change accordingly.
