6.6 Types of batteries
The data of the main types of batteries are pre-installed in the UL 10device. Other types of batteries
can also be checked and they can be charged using the available types.
♦ 00: the battery is not connected
♦ 10: air-tight aircraft lead acid electrolyte-filled batteries
♦ 11: Pb battery sealed commercial
♦ 16: Pb battery vented commercial
♦ 20: enclosed aircraft nickel-cadmium batteries
♦ 21: enclosed nickel-cadmium batteries type VARTA
♦ 30: enclosed nickel-cadmium batteries type SAFT
♦ 31: enclosed nickel-cadmium batteries type NKBN
The following types of operations can be used:
♦ 0: Discharge
♦ 1: In service
♦ 2: Charge
♦ 4: Maintenance
♦ 5: I-Charge
♦ 8: U-Charge
6.7 Programming Matrix
The above types of operations (0-8) and the 6 types of batteries (00-31) enable up to 43 possible
combinations of different charging programs.
BA Type
Operation
00 10 11 16 20 21 30 31
0 - 10 11 16 20 21 30 31
1 - 110 111 116 120 121 130 131
2 - 210 211 216 220 221 230 231
4 - 410 411 416 420 421 430 431
5 - 510 511 516 520 521 530 531
8 800 810 811 816 820 821 830 831
The program for the battery type SAFT and НКБН is executed upon customer’s request. The above
programs have no emergency program disable function. The operations should be used extremely
cautiously. See additional information about individual programs.
