CHARGER / DISCAHRGER UL10 OPERATION MAUNAL
32 © NorTec Electronics 2014
6.9.2 Program 420 stage 2
1 2 3 4
P420:S2:I-CHARGE 1 19:37:38
24.64V 04.00A 000.5AH +007MIN --.-°C
5 6 7 8 9
1 Program number
operation type 4 = maintenance
battery type 20 = enclosed aircraft nickel-cadmium battery
2 stage number = Stage 2
3 stage name = I-Charge 1
4 19:37:38 = current time
5 24,64V = current battery voltage
6 04.00A = current charging current
The charging current in this program of checking of the aircraft nickel-cadmium bat-
tery restores the nominal capacity during 1 h. 4 А is for the battery with 4Аh.
