CHARGER / DISCAHRGER UL10 OPERATION MAUNAL
© NorTec Electronics 2014
71
8 Replacement of printing paper and ribbon
8.1 Ribbon replacement
Name: ribbon (a pack of 2 pcs.)
HTZ/TKZ: 101 033 111 000
The ribbon is replaced in the following procedure:
- disconnect the device 220 V from the mains
- remove 2 knurl-head screws from the head of the printer and extract it from the body
- lift the front panel of the printer and remove it
- extract the worn ribbon from the opened printer
- pull out several centimeters from the printer
- insert the paper into the ribbon and insert the ribbon by lightly pressing the printer. The position of
adjustment of the printing ribbon: a free portion of the ribbon should be down, the wheel of the trans-
fer mechanism should be leftward
- insert the front panel into the printer
- insert the printer into its body
- tighten 2 knurl-head screws
- connect the device to the 220 V mains
- perform the self-test of the printer: the printer prints a test print-out of 3 lines when the device is
switched on by pressing the paper feed key
- switch off the device
8.2 Replacement of printing paper
Name: printing paper (a pack of 6 pcs.)
HTZ/TKZ: BT2000.40071
The paper is replaced in the following procedure:
- disconnect the device from the 220 V mains
- remove 2 knurl-head screws from the printer
- extract the printer from the body
- lift the front panel of the printer and remove it
- pull the ribbon out of the opened printer
- pull the used paper roll from the printer and tear the paper slightly
- pull the paper protruding from the printer in the direction of the paper feed
- insert the printing paper as it is shown on the body of the printer and move it as it is shown on the
body of the printer
- insert the printer into its body
- switch on the device
- actuate the paper feed and use the free hand to insert the printing paper into the receiving slot of
the printer until the paper is moved by the printer
- insert the printing paper into the ribbon and then insert the ribbon into the printer without pressure.
The position of adjustment of the printing ribbon: a free portion of the ribbon should be down, the
wheel of the transfer mechanism should be leftward
- insert the front panel into the printer
- insert the printer into its body
- tighten 2 knurl-head screws
- connect the device to the 220 V mains
- perform the self-test of the printer: the printer prints a test print-out of 3 lines when the device is
switched on by pressing the paper feed key
