7.20 Program 416. Maintenance – Pb battery vented commercial
Stage name Maximum
duration
Program number 416
Operation number 4
Operation type Maintenance
Battery type Lead acid
Manufacturing process Liquid electrolyte
Access to valves open
Battery type 16
Minimum battery capacity 10 Ah
Maximum battery capacity 400 Ah
Minimum battery voltage 2
Maximum battery voltage 30
Maximum number of batteries 15
Stage 1 (S1) Discharge Electrolyte level Sound signal
equalization
Stage 1 (S1) Discharge Discharge current 0.05 24h
а = xС (A)
Stage 1 (S1) Discharge Discharge depth 1.5 24 h
V/battery
Stage 2 (S2) Precharge Voltage chargingа 2.4 2 h
Umax = V/battery
Stage 2 (S2) Precharge Ia = xС (A) Х=0.25 2 h
Stage 3 (S3) I-Charge 1 Current = xС (A) Х = 0.25 8 h
Stage 3 (S3) I-Charge 1 Umax = V/battery 2.4 8 h
Stage 4 (S4) U-Charge 1 Umax = V/battery 2.4 8 h
Stage 4 (S4) U-Charge 1 I а= xС (A) 0.04 8 h
Stage 4 (S4) U-Charge 1 Umax = V/battery 2.4 8 h
Stage 5 (S5) Discharge Discharge current 0.05 24 h
а = xС (A)
Stage 5 (S5) Discharge Discharge depth 1.5 24 h
V/battery
Stage 6 (S6) I-Charge 2 Current = xС (A) 0.25 8 h
Stage 6 (S6
) I-Charge 2 Umax = V/battery 2.4 8 h
Stage 7 (S7) U-Charge 2 Umax = V/battery 2.4 8 h
Stage 7 (S7) U-Charge 2 I а= xС (A) 0.04 8 h
Stage 8 (S8) U-Charge 3 Umax = V/battery 2.4 2 h
Note: when the maximum output current of the device is exceeded the maximum time parameters
change accordingly.
