6.9.1 Program 420 Stage 1
1 2 3 4
P420:S1:DISCHARGE 1 19:31:43
24.06V 04.00A 000.5AH +008MIN --.-°C
5 6 7 8 9
1 Program number
Operation type 4 = maintenance
Battery type 20 = enclosed aircraft nickel-cadmium battery
2 number stage а = Stage 1
3 stage name = discharge 1
4 19:31:43 = current time
5 24,06V = current battery voltage
6 04.00A = current discharge current
The discharge current of the enclosed nickel-cadmium aircraft battery С is equal to
the nominal capacity (А), i.e. the current that discharges the battery capacity 4 Аh ful-
ly within one 1 hour. This current is 4 А.
7 000.5Ah = the current discharge capacity at the moment of
print out
8 +008MIN Maintenance program # 4 for aircraft batteries stage
1 provided for discharge duration of 6 minutes during which the check current C
should flow. It is 4 A in this case.
9 --,- °C = the temperature measurement is disabled. The re-
levant protocol print-out shows the same data in addition to the data of the opera-
tor and also the current time. The protocol is drawn up automatically at the end of
stage 1 when the remaining charging time is -00:00:00.
