NovaStar MX2000 Pro - Page 11

MX2000 LED Display Controller User Manual
www.novastar.tech
7
Min resolution: 720x480i@59.94Hz
Frame rate
23.98/24/25/29.97/30/47.95/48/50/59.94/60 Hz
HDR
HDR video is accepted with manual HDR configuration
in VMP.
Interlaced signal
inputs
Support interlaced signal inputs, including
1080i/576i/480i.
Cables
Recommend using the CANARE-12G SDI coaxial
cable. Cables up to 50 meters are supported.
MX_1xDP 1.4+1xHDMI 2.1 input card
Type
Qty
Description
DP1.4
1
Resolution
Max resolution: 7680×4320@30Hz (Forced)
Min resolution: 800×600@60Hz
Max width/height
(Forced)
Max width: 8192 pixels (8192×4320@25Hz)
Max height: 8192 pixels (4320×8192@25Hz)
Frame rates
23.98 / 24 / 25 / 29.97 / 30 / 47.95 / 48 / 50 /
59.94 / 60 / 71.93 / 72 / 75 / 100 / 119.88 / 120 /
143.86 / 144 / 240 Hz
HDR
Support HDR10 and comply with the SMPTE ST
2084 and SMPTE ST 2086 standards.
Support HLG.
EDID management
Support standard resolutions, up to
3840×2160@60Hz.
Support custom input resolutions.
HDCP
HDCP 2.3 compliant, backwards compatible with
HDCP 2.2/HDCP 1.4/HDCP 1.3.
Interlaced signal
inputs
Not supported.
Cables
Recommend using the UGREEN DP 1.4 cable.
Cables up to 5 meters are supported.
