MX2000 LED Display Controller User Manual
www.novastar.tech
14
1G Solution (4x10G Fiber Output Card)
This diagram is an example of two input cards and one 4x10G fiber output card installed on a
MX2000 Pro. The actual application may vary.
5G Solution (1x40G Fiber Output Card)
This diagram is an example of two input cards and one 1x40G fiber output card installed on a
MX2000 Pro. The actual application may vary.
