Front Screen Panel
UI Introduction
Home Screen
After the device is powered on, the home screen showing device related information is displayed
as Figure 4-1 . Rotate the knob to select an input or output card to view its details, as shown in
Figure 4-2 .
Figure 4-1 Home screen
Figure 4-2 Input and output card details
