8bit: Load capacity × 24 × Frame rate < 5G × 0.85

10bit: Load capacity × 30 × Frame rate < 5G × 0.85

12bit: Load capacity × 36 × Frame rate < 5G × 0.85
Max Load Capacity per Ethernet Port (Pixels)
Frame Rate / Bit
Depth
8bit
10bit
12bit
24 Hz
7,378,000
5,533,000
3,689,000
25 Hz
7,082,800
5,311,680
3,541,440
30 Hz
5,902,400
4,426,400
2,951,200
50 Hz
3,541,440
2,655,840
1,770,720
60 Hz
2,951,200
2,213,200
1,475,600
120 Hz
1,475,600
1,106,600
737,800
144 Hz
1,229,600
918,478
612,374
240 Hz
737,800
553,300
368,900
300 Hz
590,240
442,640
295,120
360 Hz
491,800
368,800
245,900
480 Hz
368,900
276,650
184,450
Note
When using a 5G Ethernet port to drive the LED screen, it can achieve its maximum load capacity only when the
load width is 192 pixels or more. If the load width is less than that, the load capacity will be reduced accordingly,
calculated as (192 - load width) × load height.
