OSCILLATOR SECTION
Soften - Button
Mod Depth - Knob
ENV 2 - Button
This combination controls the modulation of the Soften Effect on the selected Oscillator by ENV 2. Turning the Mod Depth Knob fully
clockwise introduces Soften Effect from ENV 2 to the selected Oscillator in a Positive direction. Turning the Mod Depth Knob fully anti-
clockwise introduces Soften Effect from ENV 2 to the selected Oscillator in a Negative direction. In the “Mid” position there is no modu-
lation at all. The range of this parameter is -64 to +63.
This does not apply to the 1*3 & 2*3 Ring Modulator outputs. No audible effect to these sound sources will be heard if an attempt
is made to adjust this parameter when these sound sources are selected & the display will show “Not Available”.
Soften - Button
Mod Depth - Knob
ENV 3 - Button
This combination controls the modulation of the Soften Effect on the selected Oscillator by ENV 3. Turning the Mod Depth Knob fully
clockwise introduces Soften Effect from ENV 3 to the selected Oscillator in a Positive direction. Turning the Mod Depth Knob fully anti-
clockwise introduces Soften Effect from ENV 3 to the selected Oscillator in a Negative direction. In the “Mid” position there is no modu-
lation at all. The range of this parameter is -64 to +63.
This does not apply to the 1*3 & 2*3 Ring Modulator outputs. No audible effect to these sound sources will be heard if an attempt
is made to adjust this parameter when these sound sources are selected & the display will show “Not Available”.
Soften - Button
Mod Depth - Knob
Wheel - Button
This combination controls the modulation of the Soften Effect on on the selected Oscillator by the Mod Wheel. Turning the Mod
Depth Knob fully clockwise introduces Soften Effect from the Mod Wheel to the selected Oscillator in a Positive direction. Turning
the Mod Depth Knob fully anticlockwise introduces Soften Effect from the Mod Wheel to the selected Oscillator in a Negative direc-
tion. In the “Mid” position there is no modulation at all. The range of this parameter is -64 to +63.
This does not apply to the 1*3 & 2*3 Ring Modulator outputs. No audible effect to these sound sources will be heard if an attempt
is made to adjust this parameter when these sound sources are selected & the display will show “Not Available”.
