Menu - Button
When this button is pressed a series of pages is available on the display containing parameters relevant to this section.
In the Oscillator section there are 3 pages available. These are selected using the Page Up & Page Down buttons to the left of the
display.
There are a maximum of 2 parameters displayed on any page. One for each line on the display. The “Fast Data” Knobs on the right
of the display are used to alter these parameter’s values.
Page 1 looks like so:
As can be seen the higher parameter is “MWheel LFO1 amt”. In this case with a value of +10.
This parameter determines how the Mod Wheel on the Master Keyboard effects the amount of LFO1 modulation on the selected
Oscillator. Use the higher Fast Data knob to adjust the value of this parameter. With this parameter it is possible to set the amount
of modulation individually for each oscillator. The range of this parameter is -64 to +63. This parameter is memorised with a
Program.
Mod Wheel LFO Amt does not apply to the 1*3, 2*3 or Noise buttons. If you attempt to alter this parameter when these buttons are
selected the display will show “Menu Only Available For Osc 1,2 or 3” whilst the adjustment is being made then the display will
revert back to the last edited parameter.
As can be seen the lower parameter is “AT LFO1 amt”. In this case with a value of +10.
This parameter determines how the Aftertouch on the Master Keyboard effects the amount of LFO1 modulation on the selected
Oscillator. Use the lower Fast Data knob to adjust the value of this parameter. With this parameter it is possible to set the amount
of modulation individually for each oscillator. The range of this parameter is -64 to +63. This parameter is memorised with a
Program.
Aftertouch LFO1 Amt does not apply to the 1*3, 2*3 or Noise buttons. If you attempt to alter this parameter when these buttons are
selected the display will show “Menu Only Available For Osc 1,2 or 3” whilst the adjustment is being made then the display will
revert back to the last edited parameter.
Page 2 looks like so:
As can be seen the higher parameter is “Formant width”. In this case with a value of 010.
This parameter determines how much Formant Width is applied to the selected Oscillator. Use the higher Fast Data knob to adjust
the value of this parameter. With this parameter it is possible to set the amount of modulation individually for each oscillator. Refer
to page 8 in the “About Analogue Synthesis section” for details on this parameter. The range of this parameter is 000 to 127. This
parameter is memorised with a Program.
Formant Width does not apply to the 1*3, 2*3 or Noise buttons. If you attempt to alter this parameter when these buttons are
selected the display will show “Menu Only Available For Osc 1,2 or 3” whilst the adjustment is being made then the display will
revert back to the last edited parameter.
