Page 3 looks like so:
As can be seen the higher parameter is “Fq AT LFO2 amt”. In this case with a value of +63.
This parameter determines how the Aftertouch on the Master Keyboard effects the amount of Modulation of the Cutoff Frequency
of the Filter from LFO 2. This produces the Growl effect. In the central position of the higher Fast Data knob there is no change to
the Filter Cutoff Frequency when the Master Keyboard’s Aftertouch is engaged. Anticlockwise of centre there will be an increasing
amount of Negative modulation. i.e. The Filter will be closed more by LFO 2 when the Master Keyboard’s Aftertouch is engaged.
Clockwise of centre the modulation is Positive. i.e. The Filter will be increasingly opened by LFO 2 when the Master Keyboard’s
Aftertouch is engaged. The range of this parameter is -64 to +63. This parameter is memorised with a Program.
As can be seen the lower parameter is “Res AT LFO2 amt”. In this case with a value of +63.
This parameter determines how the Aftertouch on the Master Keyboard effects the amount of Modulation of the Resonance of the
Filter from LFO 2. In the central position of the lower Fast Data knob there is no change to the Filter Resonance when the Master
Keyboard’s Aftertouch is engaged. Anticlockwise of centre there will be an increasing amount of Negative modulation. i.e. The Filter
will be made less Resonant by LFO 2 when the Master Keyboard’s Aftertouch is engaged. Clockwise of centre the modulation is
Positive. i.e. The Filter will be increasingly made more Resonant by LFO 2 when the Master Keyboard’s Aftertouch is engaged. The
range of this parameter is -64 to +63. This parameter is memorised with a Program.
Page 4 looks like so:
As can be seen the higher parameter is “Fq AT amt”. In this case with a value of +63.
This parameter determines how the Aftertouch on the Master Keyboard effects the amount of Modulation of the Cut-off frequency
of the Filter. In the central position of the higher Fast Data knob there is no change to the Filter Cutoff Frequency when the Master
Keyboard’s Aftertouch is engaged. Anticlockwise of centre there will be an increasing amount of Negative modulation. i.e. The Filter
will be closed more when the Master Keyboard’s Aftertouch is engaged. Clockwise of centre the modulation is Positive. i.e. The
Filter will be increasingly opened when the Master Keyboard’s Aftertouch is engaged. The range of this parameter is -64 to +63.
This parameter is memorised with a Program.
As can be seen the lower parameter is “Res AT amt”. In this case with a value of +63.
This parameter determines how the Aftertouch on the Master Keyboard effects the amount of Modulation of the Resonance of the
Filter. In the central position of the lower Fast Data knob there is no change to the Filter Resonance when the Master Keyboard’s
Aftertouch is engaged. Anticlockwise of centre there will be an increasing amount of Negative modulation. i.e. The Filter will be
made less Resonant when the Master Keyboard’s Aftertouch is engaged. Clockwise of centre the modulation is Positive. i.e. The
Filter will be increasingly made more Resonant when the Master Keyboard’s Aftertouch is engaged. The range of this parameter is
-64 to +63. This parameter is memorised with a Program.
Fq AT amt +63
Res AT amt +63
Fq AT LFO2 amt +63
Res AT LFO2 amt +63
