EFFECTS SECTION
As can be seen the lower parameter is “Early ref level”. In this case with a value of 6.
This parameter determines the level of early reflections in the reverb. Use the Lower Fast Data knob to adjust this parameter. The
range of this parameter is 0 to 7. This parameter is memorised with a Program in Program Mode or memorised with a Program or
Performance in Performance Mode depending on the value of the Part’s “Effects Used” parameter.
Page 2 looks like so:
As can be seen the higher parameter is “Reverb decay”. In this case with a value of 099.
This parameter determines the rate at which the Reverb effect decays away. Use the Higher Fast Data knob to adjust this parame-
ter. The range of this parameter is 000 to 127. This parameter is memorised with a Program in Program Mode or memorised with a
Program or Performance in Performance Mode depending on the value of the Part’s “Effects Used” parameter.
As can be seen the lower parameter is “HF damp”. In this case with a value of 020
This parameter determines the rate at which High Frequencies decay away in the Reverb & is called High Frequency Damping.
Use the Lower Fast Data knob to adjust this parameter. The range of this parameter is 000 to 127. This parameter is memorised
with a Program in Program Mode or memorised with a Program or Performance in Performance Mode depending on the value of
the Part’s “Effects Used” parameter.
Page 3 looks like so:
As can be seen the higher parameter is “Reverb wheel”. In this case with a value of +50
This parameter determines How much the Mod Wheel controls the amount of Reverb effect. Use the higher Fast Data knob to
adjust this parameter. Fully anticlockwise the Reverb will be reduced with full modulation of the Mod Wheel, fully clockwise the
Reverb will be increased with full modulation of the Mod Wheel. The range of this parameter is -64 to +63. This parameter is mem-
orised with a Program in Program Mode or memorised with a Program or Performance in Performance Mode depending on the
value of the Part’s “Effects Used” parameter.
Menu - Button ( Chorus/Flanger/Phaser selected )
When this button is pressed a series of pages is available on the display containing parameters relevant to this section.
In the Chorus/Flanger/Phaser section there are 3 pages available. These are selected using the Page Up & Page Down buttons to
the left of the display. There are a maximum of 2 parameters displayed on any page. One for each line on the display. The “Fast
Data” Knobs on the right of the display are used to alter these parameter’s values.
Page 1 looks like so:
As can be seen the higher parameter is “Type”. In this case with a value of Quad Chorus.
This parameter determines the type of effect the Chorus/Flanger/Phaser will be. Use the higher Fast Data knob to adjust this
parameter. The range of this parameter is Quad Chorus, Chorus/Flanger & Phaser. This parameter is memorised with a Program
in Program Mode or memorised with a Program or Performance in Performance Mode depending on the value of the Part’s
“Effects Used” parameter.
Type Quad chorus
Speed 1 010
Reverb wheel +5O
Reverb decay O99
Reverb HF damp O2O
