EFFECTS SECTION
Menu - Button ( Pan selected )
When this button is pressed, a series of pages is available on the display containing parameters relevant to this section.
In the Pan section there are 3 pages available.
Page 1 looks like so:
As can be seen the higher parameter is “Pan type” In this case with a value of Autopan.
This parameter determines in what way the panning effects are used. Use the higher Fast Data knob to adjust this parameter. In
the Autopan position the Program is “Panned” automatically from Left to Right & back again. In the Tremolo position both Left &
Right are controlled in sync creating the classic “Tremolo” effect. Another 2 phases are provided L-R & R-L. these are similar to
Autopan but the effect is not symmetrical. The range of this parameter is Autopan, Tremolo, L-R & R-L. This parameter is memo-
rised with a Program in Program Mode or memorised with a Program or Performance in Performance Mode depending on the
value of the Part’s “Effects Used” parameter.
As can be seen the lower parameter is “Pan speed”. In this case with a value of 040.
This parameter determines the rate at which the Autopan & Tremolo effects run. Use the lower Fast Data knob to adjust this
parameter. The range of this parameter is 000 to 127. This parameter is memorised with a Program in Program Mode or memo-
rised with a Program or Performance in Performance Mode depending on the value of the Part’s “Effects Used” parameter.
Page 2 looks like so:
As can be seen the higher parameter is “Pan depth” In this case with a value of 080.
This parameter controls the intensity of the Autopan & Tremolo effects. Use the higher Fast Data knob to adjust this parameter. In
the 000 position there is no movement of sound in the stereo field & no change to the Program’s volume ( No Autopan or Tremolo
effects will be heard ). As the value of this parameter is increased the Autopan & Tremolo have more & more effect. The range is
000 to 127 Off. This parameter is memorised with a Program in Program Mode or memorised with a Program or Performance in
Performance Mode depending on the value of the Part’s “Effects Used” parameter.
As can be seen the lower parameter is “Dry level”. In this case with a value of 020.
This parameter determines how much “Dry” signal is in the mix. Use the lower Fast Data knob to adjust this parameter. This allows
“Pre” effects “Sends” arrangements to be realised. If this parameter is set to 000 no “Dry” sound from the Program will be heard.
The sound you will hear will be 100% effect signals. i.e. If the Chorus “Send” is set to 127 & the “Dry level” parameter is set to 000
you will hear only the “Chorused” signal, none of the original. The range of this parameter is 000 to 127. This parameter is memo-
rised with a Program in Program Mode or memorised with a Program or Performance in Performance Mode depending on the
value of the Part’s “Effects Used” parameter.
