4 - 4 en-938821/2
Display of the coordinates with respect to the measurement origin (OM)
Select the page displaying the current position with respect ☞
AXIS
to the OM.
Display of the coordinates of the current position with respect to the measurement origin (OM).
Notes
The page displaying the current position with respect to OP is automatically called at power on.
Each time the
AXIS
key is pressed, the display switches between the programme origin and the measurement origin.
Pressing the
. . / . .
DAT
key causes display of the coordinates on the duplicated and synchronised axes with respect to OP
or OM.
Error during programme execution
The error number, the number of the block with the error and possibly the error message text are displayed in the
dialogue window, e.g.:
error 159 block N10
Programme shift requested on an axis for which homing is not completed.
Display of a part programme message
The first 39 characters in the message are displayed on the first line (e.g. "PART FINISHING").
