Nvidia BlueField BF1600 User Manual

16
Supported Interfaces
Layout and Connector Information
BlueField BF1600 Controller Card
The BF1600 Controller card is a 9.13 in. x 4.37 in. (232.0 mm x 111.15mm) card. The component height on the top and bottom of the card complies with
the PCIe specification. The below figures show the connector and LED designations.
BF1600 Controller Card - Component Side
The below figures are for illustration purposes only and might not reflect the current revision of the BF1600 card.

